P/N: AM78F0522A001

MINI-Change 7/8-16UNF Panel Rear Mount Receptacle Female 5Pin PCB Connector

Automation Technology Connectors - Voltage, Power Supply Manufacturer: Made in China by Amissiontech

ADD TO REQUEST

Description
Technical Data
Dimension

Your Benefits
-Easy PCB assembly for wave soldering
-Standard pin assignments and codings for signal transmission with a uniform design-in design
-For high transmission reliability: optional shield connection to the housing and latching on the PCB

Standard	\
Locking system	Fix screw locking
Gender	Female
Series	AM78
Ordering P/N	AM78F0522A001
Coding	A
Torque	1.2N.M
Category	Device connector
Connection type	PCB Solder connection
Wire gauge(max.)	\
Cable outlet	\
Custom tariff number	85444290
Country of origin	China

Electrical

Rated current	12A
Rated voltage	600V
Rated Impulse voltage	2500V
Insulation resistance	≥ 100 MΩ
EMC compliance	Unshieldable
Degree of protection	IP67
Mechanical operation	> 100 mating cycles
Operation temperature	-25 °C ~ 85 °C

Material

Flammability rating	Acc. to UL 94 V0
Contact material	Brass with Au plating
Insulation material	PA66, UL94-V0
Ring nut material	Brass with Nickle plated
Sealing material	Silicone
Molding material	Brass with Au plating
